single plate double-working station screen changer from China manufacturer

single plate double-working station screen changer

Price:	2500.0~9000.0 USD
Payment Terms:	T/T
Place of Origin:	Henan, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: DHB

Production Capacity: 50 sets per month

Delivery Date: within 30 days after down p...

Function: Screening Filter

Brand Name: Deao

Means of Transport: Ocean,Air

Packing: seaworthy packing

Structure: Hydraulic Filter

Material: Others

screen changer for extrusion lines: China made screen changer

1,single plate type double -working station screen changer
2, no materual leakage
3, non -stop the working machine

Specifications

Extruder screen changer, screen changer, automatic tooling changer, tool changer, auto screen changer, double pillar screen changer

1. Extruder screen changer with single plates.

2. Automatic tooling screen changer has different diameters for changing nets.

3. Tool changer is equipped with different extruders.

4. Auto screen changer, double pillar hydraulic screen changer with double working position, single plate screen changer, single panel screen changer, single pillar screen changer, its diameter is from 70mm-300mm.

Technical Data

Type	Screen Diameter(mm)	Heating power(Kw)	Suitable Materials (Mpa)	Output(Kg/h)
DHB-70	Φ70	4.4	≤50	60-250
DHB-100	Φ100	6.8	≤50	110-400
DHB-120	Φ120	8.6	≤50	140-550
DHB-150	Φ150	9.8	≤50	200-800
DHB-170	Φ170	9.8	≤50	300-1000
DHB-200	Φ200	11.6	≤50	400-1200
DHB-250	Φ250	16.4	≤50	600-1800
DHB-300	Φ300	16.4	≤50	800-2500

single plate type double-working station screen changer

Special installations

The DHB SERIES can be installed both horizontally and vertically and can be introduced into pre-existing installations or where the space available is restricted but without compromising high quality processing.

For maximum use of space, and economic advantage, several DHB series screen changers can be connected to one hydraulic unit.

Applications

Blown film and cast film (Bubble pack/ Medical/Food Wrap)

Sheet (Foam/Strapping/Plastic cardboard)

Coating (Hot melt adhesive)

Pipe ( Corrugated/Gas Pipe) and profile

Compounding (Master batch/filler)

Wire and cable extrusion

Tubing (Medical/Industrial/Irrigation)

Fibers ( Monofilament)

Blow molding

Pelletizing (strands and underwater)
