Hydraulic screen changer/melt filter for extrusion machine
This kind of plate screen changer, is widely used for the production of various plastics and chemical fibers. It is of high performance/price ratio, and ensures the screen changing without machine halt, or any material leakage under high pressure. Therefore, it is especially applicable to large scale machines of film blowing, pipe making, plate making and granulating, etc.
| Screen Diameter(mm) | Heating power(Kw) | Suitable Materials (Mpa) | Output(Kg/h) |
DHB-70 | Φ70 | 4.4 | ≤50 | 60-250 |
DHB-100 | Φ100 | 6.8 | ≤50 | 110-400 |
DHB-120 | Φ120 | 8.6 | ≤50 | 140-550 |
DHB-150 | Φ150 | 9.8 | ≤50 | 200-800 |
DHB-170 | Φ170 | 9.8 | ≤50 | 300-1000 |
DHB-200 | Φ200 | 11.6 | ≤50 | 400-1200 |
DHB-250 | Φ250 | 16.4 | ≤50 | 600-1800 |
DHB-300 | Φ300 | 16.4 | ≤50 | 800-2500 |
This kind of hydraulic screen changer/melt filter with different appreance
This hydraulic screen changer/melt filter is widely uded forBlown film and cast film (Bubble pack/ Medical/Food Wrap)
Sheet (Foam/Strapping/Plastic cardboard)
Coating (Hot melt adhesive)
Pipe ( Corrugated/Gas Pipe) and profile
Compounding (Master batch/filler)
Wire and cable extrusion
Tubing (Medical/Industrial/Irrigation)
Fibers ( Monofilament)
Blow molding
Pelletizing (strands and underwater)
Recycling of most polymers
PVC Profile extrusion line
.PVC.PE.PP Wood-plastic profile extrusion line
.PVC wood door panel extruding production line
.Corrugated pipe production line
.co-exyrusion single screw extruder
.granulation line
.PVC foamed plate production line
.PC.PMMA.PS.MS sheet production line
.PP.HIPS.PE.EVA.EVAOH single screw multi-layers composite sheet production line
PP.PE board production line
.PMMA transparent sheet production line
.PC.PP hollow profile board production line
.ABS single layer,multi-layers composite sheet production line
.ABS.PP.PS anti-static co-extrusion sheet prduction line
.Wide floor seet,waterproof shet production line
.PVC free foamed sheet, board,production line
